Description Specification Camera Video System: 1080P, 720P, 540P, 480P, 360P, 240P etc. Sensor: 1/2.8”, CMOS, Effective Pixel: 2.07M Scanning Mode: Progressive Lens: 10x, f4.7mm ~ 46.3mm, F1.8 ~ F2.8 Digital Zoom: 16x Minimal Illumination: 0.5 Lux @ (F1.8, AGC ON) Shutter 1/30s ~ 1/10000s White Balance: Auto, 3000K/Indoor, 4000K, 5000K/Outdoor, 6500K_1, 6500K_2, 6500K_3, One Push, Manual, VAR Backlight Compensation: Support Digital Noise Reduction: 2D&3D Digital Noise Reduction Video S/N: ≥55dB Horizontal Angle of View: 58.5° ~ 6.5° Vertical Angle of View: 35.1° ~ 3.6° Horizontal Rotation Range: ±170° Vertical Rotation Range: -30° ~ 90° Pan Speed Range: 2.7° ~ 35.7°/s Tilt Speed Range: 2.7° ~ 31.5°/s H & V Flip: Support Image Freeze: Support Number of Preset: 255 Preset Accuracy: 0.1° USB Features Operating System: Windows 7, Windows 8, Windows 10, Mac OS X, Linux, Android Colour System: / YUY2 / H.264 / MJPEG Video Formats: H.264 AVC: max to 1080P@30fps | H.264 SVC: max to 1080P@30fps | MJPEG: max to 1080P@30fps USB Video Communication Protocol: UVC 1.0 UVC PTZ: Support Input/Output Interface Input Voltage: DC 12V Current Consumption: 0.5A (Max) Operating Temperature: -10°C ~ 40°C Storage Temperature: -40°C ~ 60°C Power Consumption: 5W (Max) MTBF: >30000h Size: 141.3mm x 153mm x 163.6mm Net Weight: 1.153 KG USB Interface: 1xUSB2.0: Type B female jack Communication Interface: 1xRS232 In: 8pin Min DIN, Max Distance: 30m, Protocol: VISCA/Pelco-D/Pelco-P Power Jack: JEITA type (DC IN 12V) / USB B type（DC IN 5V) Generic Specification Input Voltage: DC 12V / POE (802.3af) Current Consumption: 1.0A (Max) Power: 12W (Max) Size: 146mm x 152mm x 164mm Net Weight: 1.35Kg Remember – if you need help or advice that’s what we’re here for  Edis V20C Datasheet Edis V20C User Manual
