Saleae 8 Channel Logic Analyzer (Replica) – 24M Max Sample Rate
BOA BALL PEN
Product Code: TPC551905
A high gloss twist action ball pen, made in Germany using climate-neutral production and 100% green electricity. 20% of the plastic used to produce this product is made from recycled ABS plastic! This promotional pen is made to order and you can customise the individual parts of the pen. You can pick between a wide range of 14 different standard colours and from 3000pcs you can even pantone match the parts! This twist action ball pen is sure to stand out, not only with your colour combinations, but also the sleek and precise design will catch the attention of anyone. Supplied with a quality Silktech refill, made of recycled PP material, that is guaranteed to have a write out length of 3000m and can be supplied in blue or black ink. A combination of precise design and engineering oozes quality and ensures a writing experience like no other. Get in touch today and order now!
Description This is a very affordable 24Mhz 8 Channel USB Logic analyzer. A logic analyzer is a must have tool for any serious electronics hobbyist. With a logic analyzer it is possible to see a visual representation of the zeros and ones that are flashing by between two components. A logic analyzer is different from an oscilloscope because the analyzer allows you to capture the data on a PC for a more detailed analysis of the data which is being transmitted and received. This logic analyzer supports 10 different communications standards (see Specifications below). with 8 channels it will allow you to monitor upto 8 different wires. For example you can monitor the Serial port (tx/Rx pins), the I2C Interface, and the SPI Interface all at the same time. Features 8 Channels Fully compatible with Saleae Logic softwares Supports different trigger types. (Rising, Falling, High and Low) The sampling frequency up to 24MHz Maximum Working Voltage: 5,25 V DC Supported Protocols: CAN DMX-512 I2C I2S/PCM Manchester 1-Wire Async Serial Simple Parallel SPI UNI/O Technical Specifications Possible Sample rates: 24 MHz , can be 24MHz. 16MHz, 12MHz, 8MHz, 4MHz, 2MHz, 1MHz, 500KHz, 250KHz, 200KHz, 100KHz, 50KHz, 25KHz No of Channels: 8 Voltage range: Input voltage range: -0.5V to 5.25V Input Low Voltage: -0.5V to 0.8V Input High Voltage: 2.0V to 5.25V Works with 5V, 3.3V, 2.5V, 2.0V systems. May work with 1.8V but not recommended. Input Impedance: 1Mohm || 10pF (typical, approximate) Crystal: /-20ppm, 24MHz Error/Accuracy: pulse-width measurement: /- 42ns (at 24MHz [!] Important 24M/16Msps rate may not work on some USB ports which have slower datarates. Use short length USB cables to improve capture rates Documents and Downloads Download Saleae Logic Analyzer Software here Hackaday article on Saleae 8-Channel logic analyzer 8-Channel Saleae Logic Analyzer support page Known issues in the latest Logic Software Package Includes 1x Saleae 8 Channel Logic Analyzer (Made in China) – QC OK by Art of Circuits 10x Female to Female probes 1x USB cable [!] Note: These logic Analyzer are functionally same as Saleae Logic Analyzer. Every logic analyzer is tested by Art of Circuits with Saleae official software before putting them on sale. The devices may or may not have Saleae text printed on their label.
