LCD Digital AC Voltage Current Power Energy Panel Meter 80-260V/20A – D021

Description Displays voltage, current, power, energy parameters from the large back-lit LCD screen simultaneously. Applications AC Voltage, current, power and energy measurement in home or office Can be used in power distribution box as voltage, current power,  and energy indicator Use in process monitoring to measure AC Input voltage, current, power and energy consumption of Motors, Actuators etc. Technical Specifications Model: D021 Working voltage: 80 ~ 260VAC Test voltage: 80 ~ 260VAC Rated power: 20A / 4500W Working Frequency: 45-65Hz LCD Back Light color: Blue Display Format 1. Power: measurement range 0 ~ 4.5kW 1kW display format within 0.0 ~ 999.9W; From 1kW display format 1000 ~ 4500W. 2. Power: measurement range 0 ~ 9999kWh 10kWh within the display format 0 ~ 9999Wh; Above 10kWh display format 10 ~ 9999kWh; 3. Voltage: Test Range 80 ~ 260V Display Format 80 ~ 220V 4. Current: Test Range 0 ~ 20A Display Format 0.00 to 20.00. Operating Instructions Multi-function single Button can be used to program or reset the 4 in 1 meter as mentioned below: 1. Backlight control By short press the button to turn on or off the backlight, the backlight status automatic storage. 2. Clear / Reset Energy Metering history Step 1: Press the power button 5 seconds until the digital display window flashes, then release the button; Step 2: If you press the button again, the consumption data is cleared and cleared quit flashing; Step 3: If you press the button again 5 seconds long until no flashing, the charge data is not cleared and exit cleared. 3. Set the Alarm value Step 1: Press the button, when the LCD screen display “SET CLr” after the release button, set the value into the power status report; Step 2: Power area displays the current value of the power alarm and the lowest digit starts blinking, then you can press the button of the digital 1, when there is no key operation more than three seconds, automatically switches by short digital set as above; Step 3: After setting, press the button more than five seconds to automatically save and exit, the scope of active power threshold set for the 0.0 ~ 4.5kW. Package Includes 1x LCD Digital AC Voltage Current Power Energy Panel Meter 80-260V/20A – D021
