Description L293D Dual Motor Shield has two L293D motor drivers and one 74HC595 shift register. The shift register expands 3 pins of the Arduino to 8 pins to control the direction for the motor drivers. The output enable of the L293D is directly connected to PWM outputs of the Arduino. Features Can drive 4 DC motors or 2 stepper motors or 2 Servo Up to 4 bi-directional DC motors with individual 8-bit speed selection Up to 2 stepper motors (unipolar or bipolar) with single coil, double coil or interleaved stepping. 4 H-Bridges: per bridge provides 0.6A (1.2A peak current) with thermal protection, can run motors on 4.5V to 36V DC Pull down resistors keep motors disabled during power-up reset button 2 external terminal power interface, for seperate logic/motor supplies Tested compatible for Mega, Diecimila & Duemilanove Documents and Downloads Schematics and Eagle Board files Arduino Library for Motor Dual Shield Related Links: Product Support Page Forum Discussion Datasheet (L293D): http://www.st.com/web/en/resource/technical/document/datasheet/CD00000059.pdf Package Includes 1x Motor Drive Shield L293D Art of Circuits eShop is Pakistan’s popular online store that sells electronics components, boards and tools to make your electronics projects possible. Art of Circuits is located in Islamabad, and sells products across all cities of Pakistan.
